Battery material
XWELL supplies battery materials and accessories for lithium battery production and pack assembly, including raw materials, pack accessories, supporting materials and related consumables. These products can be purchased together with battery machines to simplify sourcing.
This category is suitable for lab preparation, pilot production and battery pack manufacturing projects. Please tell us your battery type, material specification, required quantity and application so we can help match suitable materials and accessories.
27148/28148/29148 Aluminum Shell Prismatic cell Battery Battery Bracket – Free Assembly
Material:ABS+PC (black, environmental protection)
Flame Retardant Grade:94V0
Working Temperature Range:-40℃ ~ +85℃
Installation Method:Splicing + Bolt Fixation
Color:Black
Applicable Cell Size:length 148mm, height unlimited, thickness 27mm/28mm/29mm
MOQ: 100pcs
Leading time: 5-8 working days
FR4 Epoxy Board and Phenolic Paper Board – 0.5mm Fiberglass Insulation Sheet with Custom Processing and 150℃ Temperature Resistance
Model:3240 Epoxy Board
Material:Phenolic Resin 3240 Epoxy Board
Temperature Resistance:150 (℃)
Color:Yellow
Thickness:Customizable (mm)
Width:Customizable (mm)
Length:Available
MOQ: 10pcs
Leading time: 5-8 working days
130AH Prismatic Cell ABS+PC Fireproof Prismatic Battery Bracket Connection Bracket and End Face Bracket
Material:ABS+PC
Application:Prismatic battery 130AH
Color:Black
Cell Dimensions:174 × 114 × 50
MOQ: 10pcs
Leading time: 5-8 working days
ABS+PC Fireproof Prismatic Battery Bracket for 100AH Prismatic Cell with Fully Enclosed Splicing Structure
Material:ABS+PC
Application:Prismatic battery 100AH
Color:Black
Cell Dimensions:174*127*48
MOQ: 10pcs
Leading time: 5-8 working days
Customizable Size & String Count Epoxy Board Bracket with 150℃ Temperature Resistance and High Dielectric Performance for Battery Insulation
Model:3240 Epoxy Board
Material:Epoxy Board
Temperature Resistance:150 (℃)
Color:Yellow
Product Certification:Available
MOQ: 10pcs
Leading time: 7-10 working days
Air-cooled Heat-insulating Aluminum Panel For Prismatic Cell Battery Pack
Place of Origin:China
Material:Aluminum
size:Customizable
thickness:5mm-15 mm
tolerance:+/-0.1 mm or even 0.01 mm
Application range:For 100Ah/200Ah/300Ah Prismatic Cell Battery Pack
MOQ: 10pcs
Leading time: 7-10 working days
Customized CCS Cells Contact System for Prismatic cell Battery Pack
Product Name:CCS Cells Contact System for Prismatic Cell Battery Pack
Core Function:Integrates busbar, insulation structure & connection terminals; realizes reliable series-parallel connection of prismatic cells
Conductor Material:Tinned copper / Nickel-plated copper / Aluminum
Insulation Material:PA66/PPO/PEEK
Contact Resistance:≤0.001Ω (low energy loss)
Working Environment:-40℃~+85℃, ≤1500V DC, IP54
Applicable Cell Type:Prismatic lithium-ion battery
Application Fields:EVs, hybrid vehicles, ESS
MOQ: 50pcs
Leading time: 5-8 working days
Prismatic Battery Pack-Specific Custom CCS Contact & Current Collection System
Battery spacer holder:Prismatic lithium-ion battery
Conductor Material:Tinned copper / Nickel-plated copper / Aluminum
Insulation Material:PA66/PPO/PEEK
Working Voltage:≤1500V DC
Current Capacity:Customizable up to 800A
IP Rating:IP54
MOQ: 100pcs
Leading time: 5-8 working days
Insulation Highland Barley Paper for XWELL Battery Insulation Paper Sticking Machine
Material:Fluoroplastic-Processed Barley Paper
Thickness:0.2mm
Width:99mm
Length:100m
Temperature Resistance:130℃
Voltage Resistance:4000v
MOQ: 10pcs
Leading time: 5-8 working days
Premium Porous Foam Nickel Nickel Metal Foam – Electrochemical Electrode Catalyst Support for New Energy Applications – Electrochemical Electrode Catalyst Support
Material:Nickel Foam
Porosity:≥98%
Product Thickness:0.04mm–25mm
Areal Density:280–1800 g/m²
Pore Size:5 ppi–120 ppi (customizable)
Temperature Resistance:≤600°C (800°C in vacuum environment)
MOQ: 10pcs
Leading time: 5-8 working days
PVC Heat Shrink Tubing – Flame Retardant Insulation Sleeves for 18650 Battery Pack Protection, Shrink Wrap Film
Model: PVC
Application: cylindrical battery pack insulation and heat shrink protection
Configuration: customizable
Certification: CE
MOQ: 1 pcs
Warranty: 1 year
Flame-Retardant Blue PVC Heat Shrink Tube for 18650 Cylindrical Battery Pack Insulation
Model: Flame-Retardant
Application: cylindrical battery pack insulation and heat shrink protection
Configuration: customizable
Certification: CE
MOQ: 1 pcs
Warranty: 1 year
18650 Staggered Splicing Battery Holder – V0 Flame Retardant, Interchangeable 1X2/1X3/1X4/1X5/1X6/1X10/1X13 for Lithium Battery Packs
Splicing Specifications:Standard modules: 1X2, 1X3, 1X4, 1X5, 1X6, 1X10, 1X13
Material:V0 Flame-Retardant Grade Plastic (ABS/PC optional)
Cell Slot Diameter:18.3–18.5mm (fits all standard 18650 cells)
Splicing Method:Male-female snap joints
Key Features:Staggered splicing, interchangeable modules, precise fixation, fireproof, anti-collision
Dimensions (Sample):detailed sizes
Temperature Range: -20℃ to 120℃
Customization: Hole positions, colors, and grid layouts
Applicable Battery Models: 18650, 21700, 26650, 32650 cylindrical lithium batteries
MOQ: 100pcs
Leading time: 5-8 working days
Premium 18650 Lithium Battery One-Piece Holder, Non-Disassemblable, 19mm Cell Center Spacing
Applicable Battery Model:18650 cylindrical lithium batteries
Material:V0 Flame-Retardant ABS+PC Composite Material
Structure:Non-Detachable Integrated Structure
Key Dimensions:Battery center distance: 19mm; Aperture: 18.4mm
Customization Range:Any size within 1×1~11×18 specifications
Features: Anti-fall, explosion-proof, stable, flame-retardant, precise fit
Application: 18650 battery pack assembly, portable power stations, electric tools, energy storage devices, backup power systems
MOQ: 10pcs
Leading time: 5-8 working days
Premium 18650 Lithium Battery Offset One-Piece Holder, Non-Disassemblable, 19.2mm Cell Center Spacing
Applicable Battery Model:18650 cylindrical lithium batteries
Material:V0 Flame-Retardant ABS+PC Composite Material
Structure:Non-Detachable Integrated Structure
Key Dimensions:Battery center distance: 19.2mm; Aperture: 18.4mm
Customization Range:Any size within 2×2~6×15 specifications
Features: Anti-fall, explosion-proof, stable, flame-retardant, precise fit
Application: 18650 battery pack assembly, portable power stations, electric tools, energy storage devices, backup power systems
MOQ: 10pcs
Leading time: 5-8 working days
ABS Battery Plastic Case – 12V7AH Storage Battery Enclosure for Monitoring, Street Light Power Supplies, Sprayers, Security Systems, Kids’ Electric Vehicles, UPS & Access Control Backup Power Supplies
Applicable Battery Type:18650 Lithium Battery Cells
color:Black, yellow, blue, green
Material:ABS (94V0 Fire-Rated)
Model:12V7AH
External Dimensions:65.1 × 150.4 × 93 mm (L × W × H)
Internal Dimensions: 60.1 × 145.4 × 88.4 mm (L × W × H)
Included Accessories: Nickel sheets, mounting hardware
Key Applications: 12V7AH batteries, power storage, backup systems
Working Temperature: -40℃ ~ +85℃
Customization Scope: Color, Size, Thickness, Opening Design, Logo Printing
MOQ: 10pcs
Leading time: 5-8 working days
18650 Battery Holder Case kit, 12V 7Ah Lithium Battery Box, 3S 40A BMS with Balance Separate Port for UPS Inverter
Applicable Battery Type:18650 Lithium Battery Cells
Battery Pack Specification:12V 7Ah (3S Configuration)
BMS Parameters:3S 40A, with cell balancing, split port
Welding Compatibility:Compatible with Spot Welding, Laser Welding
Housing Material:High-Strength Flame-Retardant ABS/PC
Internal Dimensions: 60.1 × 145.4 × 88.4 mm (L × W × H)
Application: UPS Systems, Inverters, Backup Power Supplies, Portable Energy Storage
color: Black, yellow, blue, green
MOQ: 10pcs
Leading time: 5-8 working days
