Lithium Phosphorus Sulfur Chloride LPSCI Sulfide Solid Electrolyte Research Experiment
Model:Li₅.₅PSCl₁.₅
Chemical Formula:Li₇₋ₓLa₃Zr₂₋ₓ(Nb,Ta)ₓO₁₂ (x=0.2-0.7)
Ionic Conductivity:≥6 mS/cm (25°C)
Particle Size:D₅₀<15μm, D₉₀<35μm
Morphology:0-5V vs. Li⁺/Li
Electrochemical Window:0-5V vs. Li⁺/Li
Purity:≥99.9%
Storage:Argon glovebox (<0.1ppm O₂/H₂O)
MOQ: 10g
Leading time: 5-7 working days
Lithium Phosphorus Sulfur Chloride LPSCI Sulfide Solid Electrolyte ≥6mS/cm All-solid-state Battery Material Research Experiment
Material Overview
LPSCI (Li₅.₅PSCl₁.₅) is a high-performance sulfide solid-state electrolyte characterized by its irregular particle morphology (D₅₀<15μm) and exceptional ionic conductivity (≥6 mS/cm at 25°C). The SU8600 SEM image (20.0kX magnification) reveals its distinctive rough-textured particles optimized for all-saolid-state battery research.
Key Specifications
| Property | Specification | Verification Method |
|---|---|---|
| Chemical Formula | Li₅.₅PSCl₁.₅ | XRD/EDS Analysis |
| Ionic Conductivity | ≥6 mS/cm (25°C) | AC Impedance (300MPa) |
| Particle Size | D₅₀<15μm, D₉₀<35μm | Laser Diffraction |
| Morphology | Irregular rough-surface | SEM Imaging (3.00kV) |
| Electrochemical Window | 0-5V vs. Li⁺/Li | Linear Sweep Voltammetry |
Performance Highlights
1. Ultra-High Conductivity
• Achieves 2× higher Li⁺ transport than conventional Li₆PS₅Cl (3 mS/cm)
• Low activation energy (0.20-0.25 eV) enables stable performance at -20°C
2. Interface Engineering
• Rough particle surfaces enhance electrode-electrolyte contact (30% lower interfacial resistance)
• Chlorine substitution suppresses H₂S generation vs. pure sulfide systems
3. Research Applications
• Prototyping of 400+ Wh/kg all-solid-state batteries
• Compatible with:
- Li-metal anodes (CCD >2 mA/cm²)
- High-voltage NCM811 cathodes (4.3V)
Microstructural Analysis
(Per SU8600 SEM at 20.0kX Magnification)
• Particle Distribution: Broad size range (2-35μm) ensures dense packing
• Surface Texture: Nano-scale roughness promotes electrolyte wetting
• Defect Characteristics: Minimal cracks/voids (<1% area fraction)
Handling Protocol
| Step | Requirement |
|---|---|
| Storage | Argon glovebox (<0.1ppm O₂/H₂O) |
| Processing | Cold-press at 300-400 MPa |
| Safety | H₂S detectors mandatory |
Note: Custom particle size fractions (e.g., <10μm) available for thin-film battery research.
