High Density MPP Foam | Fire Retardant | Anti-Slip & Shock Absorption | New Energy Battery Special Pad
Material:Flame-retardant polypropylene foam
Color:White
Density:40±8 kg/m³
Thermal Conductivity:0.041 W/m·K
Compression Property (MPa):10%: 0.1≤α≤0.3; 50%: 0.2≤α≤0.5; 70%: 0.4≤α≤0.8
Heat Distortion Temperature (℃): ≥80
Compression Stress Retention: ≥20%
Tensile Strength (MPa): ≥1.3
Flame Retardancy: HF-01
Flatness (mm): ≤4
MOQ: 100pcs
Leading time:7-10 working days
High Density MPP Foam | Fire Retardant | Anti-Slip & Shock Absorption | New Energy Battery Special Pad
Product Overview
Our high-density anti-slip and shock-absorbing MPP foam pad is a professional buffer material specially designed for new energy batteries. It is made of polypropylene as the base material, added with flame retardant, and formed by clean supercritical carbon dioxide foaming technology, which creates a large number of micron-sized bubbles inside, making it a high-performance porous foam material. It integrates fire retardancy, shock absorption, anti-slip, and environmental protection, and is widely used as a battery spacing buffer pad in new energy battery packs, energy storage equipment, and other fields.
Key Features
- High Flame Retardancy: UL 94 HF-01 flame retardant grade, effectively preventing fire spread, ensuring the safety of battery packs in high-temperature and harsh environments.
- Zero VOC & Eco-Friendly: Clean and environmentally friendly, zero volatile organic compounds, non-toxic and harmless, compliant with ROHS and REACH international standards, no pollution to the environment.
- Lightweight & High Strength: Light weight but strong load-bearing capacity, reducing the overall weight of the battery pack while providing reliable buffer protection.
- Anti-Slip & Shock Absorption: High density and excellent buffer performance, effectively absorbing impact, reducing vibration, and preventing battery displacement and damage.
- Multi-Protection Performance: Good water resistance, chemical resistance, and surface protection, isolating moisture, corrosion, and external scratches, extending the service life of batteries.
- Recyclable: Non-crosslinked and recoverable, recyclable and reusable, conforming to the concept of green development.
Technical Specifications
| Item | Details | Test Standard / Remarks |
|---|---|---|
| Color | White | Customizable |
| Density | 40±8 kg/m³ | GB/T 6343-2009 |
| Thermal Conductivity | 0.041 W/m·K | GB/T 10295-2008 |
| Hardness (Shore C) | 60±5 | GB/T 531.2-2009 |
| Heat Distortion Temperature | ≥80℃ | GB/T 1634.2-2004 |
| Flame Retardancy | HF-01 | UL 94 |
| Water Absorption | ＜0.5% | ASTM D570-98 |
| Compression Property (MPa) | 10%: 0.1≤α≤0.3; 50%: 0.2≤α≤0.5; 70%: 0.4≤α≤0.8 | GB/T 1041-2008 |
| Compression Stress Retention | ≥20% | GB/T 1685-2008 |
| Tensile Strength | ≥1.3 MPa | ASTM D3574-2008 |
| Tensile Modulus | ≥2.8 MPa | ASTM D3574-2008 |
| Shear Strength | ≥1.1 MPa | ASTM C273/C273M |
| Shear Modulus | ≥1.2 MPa | ASTM C273/C273M |
| Low Temp Tensile Strength (-30℃) | ≥1.3 MPa | Stored at -30℃ for 4h |
| High Temp Tensile Strength (60℃) | ≥1.0 MPa | Stored at 60℃ for 4h |
| Tensile Strength after Temp Cycle | ≥1.0 MPa | -40℃~95℃, 200 cycles |
| ROHS | Compliant | SGS Certified |
| REACH | Compliant | SGS Certified |
Applications
Widely used in new energy industry and related fields, mainly for:
- New energy battery packs (lithium battery, sodium battery, aqueous zinc battery) spacing and buffer
- Energy storage equipment, battery module shock absorption and protection
- Electric vehicle battery pack internal buffer, anti-slip and scratch prevention
- Electronic equipment, precision components buffer and protection
Why Choose Us?
- Fully Customizable: We cut to any shape & size (send your drawing/specs) – perfect for unique project needs.
- Customization Service: Support customization of thickness, size, density, and flame retardant grade according to your drawings and requirements
- Quality Assurance: Strict quality inspection before delivery, conforming to international standards
