Air Electrode for Neutral Electrolyte Batteries – Al-Air, Mg-Air, Seawater Fuel Cell Electrode
Product Model:Alkaline Air Electrode
Standard Sizes:155*135mm, 190*135mm, 200*150mm/Customized
Water pressure resistance:5000 Pa
Thickness:0.9mm±0.1mm
Working Medium:4 mol/L~8 mol/L KOHaqueous solution
Areal Density: 1200 g/㎡ - 1360 g/㎡
Power Density: 0.35W/c㎡ - 0.4W/c㎡
Appearance: Smooth and flat surface; no burrs, defects, cracks, folds, fine particles or contaminants on the edges; no bubbles or delamination on the surface
MOQ: 1pcs
Leading time: 3-5 working days
Air Electrode for Neutral Electrolyte Batteries – Al-Air, Mg-Air, Seawater Fuel Cell Electrode
Product Overview
Our air electrode is a high-performance core component specially designed for neutral electrolyte batteries, compatible with Al-Air, Mg-Air batteries, and seawater/fuel cells. It is perfectly suitable for neutral electrolytes such as sodium chloride, potassium chloride, and seawater, featuring ultra-high energy efficiency, excellent safety, and long service life. With air-permeable and hydrophobic properties, simple operation, and hard to damage, it is an ideal choice for various neutral electrolyte battery applications, supported by factory-direct supply and customizable specifications.
Key Specifications
| Item | Details |
|---|---|
| Applicable Batteries | Al-Air battery, Mg-Air battery, neutral electrolyte fuel cell, seawater battery |
| Applicable Electrolyte | Neutral electrolytes (sodium chloride, potassium chloride, seawater, etc.) |
| Standard Sizes | 155*135mm, 190*135mm, 200*150mm |
| Core Performance | Ultra-high efficiency, high temperature resistance, high strength, long lifespan |
| Customization | Multiple specs customizable (size, performance parameters) |
Core Advantages
- Premium & Eco-Friendly Material: Adopts high-quality green materials, exquisite texture, durability, and reliable quality.
- Excellent Conductivity & Stability: Outstanding structural stability, maintaining a flat and stable shape, ensuring stable current transmission.
- Air-Permeable & Hydrophobic: Effectively isolates electrolyte while ensuring air circulation, simple to operate and not easy to break.
- Superior Performance: High temperature resistance, high strength, ultra-high energy efficiency, and long lifespan, adapting to harsh working environments.
- Factory Direct & Cost-Effective: No middlemen, competitive price; multiple standard sizes available, fully customizable to meet diverse needs.
Application Fields
Widely used in neutral electrolyte battery systems, including:
- Al-Air and Mg-Air batteries (portable power, emergency backup power)
- Seawater fuel cells, marine power systems
- Neutral electrolyte energy storage devices
- Specialized batteries for industrial, marine, and emergency scenarios
Customization & Supply
- Customizable size, performance parameters to match your specific battery design.
- Free samples for quality testing (shipping fee at buyer’s cost; refundable on bulk orders).
- MOQ: Flexible, supports small-batch trial and large-volume mass production.
- Factory direct supply, fast delivery (7-15 working days for bulk orders), global shipping available.
Contact Us
For quotations, free samples, or customization inquiries (specify size, battery type, or performance needs), contact our professional team. We reply within 24 hours with personalized solutions!
